New Products

AV-2MFBC3 Sanitary 3-Way Manual Full Bore Ball Valve With Tri-Clamp Ends

Specifications: Size 1/2”-4”(DN10-DN100) Working temperature -20°C - +150°C Working pressure 10 Bar (145psi) Body material 304, 316L Sealing material EPDM, VMQ, FPM Connection Tri-clamp, welded, threaded Finishing 0.4-0.8 μm Standards 3A, DIN, SMS, IDF, RJT, BEP, ISO

AV-1MBC3 Sanitary Manual 3-Pieces Butterfly Valve With Welded Ends

Specifications: Size 3/4”-6” Working temperature -10°C - +95°C Working pressure 10 bar (145psi) Body material 304, 316L Sealing material VMQ, FPM, EPDM Finish < 0.4μm Connection Welded Standards ISO, DIN, IDF, SMS, 3A

AV-2PFBC Sanitary 3-Way Pneumatic Full Bore Ball Valve With Tri-Clamp Ends

Specifications: Size 1/2”-4”(DN10-DN100) Working temperature -20°C - +150°C Working pressure 10 Bar (145psi) Body material 304, 316L Sealing material EPDM, VMQ, FPM Connection Tri-clamp, welded, threaded Finishing 0.4-0.8 μm Standards 3A, DIN, SMS, IDF, RJT, BEP, ISO

AV-1HTE High Performance Electric Two Way Ball Valves, Threaded Ends With Brass Body

Specifications: Size 1/2”-2”(DN15-50) Working temperature 1°C-95°C Nominal pressure 2.0MPa Body material Brass Connection Threaded Medium Water Sealing material NBR Standards ISO228

AV-20 Sanitary Filling Valve With Internal Sealing

Specifications: Size ΦD=12-20 mm Working temperature -10°C - +80°C Medium temperature -10°C - 120°C Controlling pressure 3-3.5 bar(44-51psi) Working pressure 0-7 bar(0-102psi) Body material 316 Sealing material PTFE

AV-5SPA3 Sanitary Pneumatic 3-Way Angle Seat Valve With Tri-Clamp Ends

Specifications: Size DN15- DN50 Controlling pressure 3~8 bar(43.5~116 psi) Working pressure 0~16 bar(0~232 psi) Medium temperature -10°C - +180°C Working temperature -10°C - +80°C Body material 316 Cylinder material 304 Sealing material PTFE Connection Threaded, tri-clamp Medium Water, stream, oil, neutral liquids, organic solvent, etc....

AV-5SPA Sanitary Pneumatic Proportional Control Angle Seat Valve With Threaded Ends

 Specifications: Size DN8-DN80 Medium temperature PTFE(-10 ~ +120°C) Working temperature 0 ~+60°C Working pressure 4-7 bar(58-102 psi) Body Material 316L Sealing material PTFE Connection Threaded, welded, tri-clamp and flange Powder consumption <5 W Leakage class DIN EN 12266 A Analogue signal output 0/4-20mA, 560Ω max....

AV-5SEA Sanitary Electric Proportional Control Angle Seat Valve With Threaded Ends

Specifications: Size DN15-DN80 Driving power 220V AC or 24V AC Control powder 4~20 mA or 0-10V DC Working temperature 0°C ~+50°C Working pressure 4-7 bar(58-102 psi) Body Material 316L Connection Threaded, welded, tri-clamp and flange Protecting class IP54 Leakage class DIN EN 12266 A

AV-2MBC Sanitary Butterfly-type Ball Valve With Welded Ends, Manual Type

Specifications: Size 1"-4"/DN25-100 Working temperature EPDM(-40 ~ +120°C) Working pressure 0-10 bar (0-145psi) Body Material 316L/304 Sealing material EPDM,VMQ,FPM Connection Tri-clamp, Welded, thread, flange Finishing Polished Standards 3A, DIN, SMS, IDF,RJT, BPE, ISO

AV-2PBC Sanitary Butterfly-type Ball Valve With Welded Ends, Pneumatic Type

Specifications: Size 1"-4"/DN25-100 Working temperature EPDM(-40 ~ +120°C) Working pressure 0-10 bar (0-145psi) Body Material 316L/304 Sealing material EPDM,VMQ,FPM Connection Tri-clamp, flanged, welded, or others upon request Finishing Polished Standards 3A, DIN, SMS, IDF, RJT, BPE, ISO

AV-1PPB Sanitary Pneumatic Powder Butterfly Valve with Tri-clamp Ends

Specifications: Size 4”-10”/DN100-250 Working atmosphere  vacuum, temperature up to 130°C, CIP cleaning and SIP sterilization Outside surface Matte, light, sandblast and electronic polishing Body Material 316L, 316 Sealing material SILICON, FKM Connection Tri-clamp, weld, flange, bottom flange Surface  Ra0.6μm; Ra0.4 μm Standards 3A, DIN, SMS,...

AV-4BMC Sanitary Diaphragm Bleed Valve With Tri-clamp Ends, Manual Type

Specification Type Diaphragm Valve Reference No. AV-4BMC Sizes 1/2" to  4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") Diameter Nominal DN15 to DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve material Body: cast iron, ductile iron, carbon steel, 316L, 304,...
