Stainless Steel Sanitary Fittings

Adamant Valves carries a wide range of sanitary fittings at some of the lowest prices online. They were developed and are used because they are cleanable; either by dismantling a system and manually cleaning it or using a CIP (clean in place) process. They limit entrapment areas where bacteria could form or harbor. They are also corrosion-resistant.

Type: Fittings
Reference No.: SS
Sizes: 1″ – 12″
End Types: Butt-weld, tri-clamp, and I-line
Grades: 304 – 316L
Operation: Manual, Pneumatic, Electric

Adamant Valves SS series stainless steel sanitary fittings use:
SS series stainless steel sanitary fittings are widely used to the petroleum, metallurgy, plumbing, food, biopharmaceutical, and chemical industries;
SS series stainless steel sanitary fittings are high-quality products. They can be used for dairy, pharmaceutical, beer, beverage, edible oil, and other industries to meet their professional requirements.

Adamant Valves SS series stainless steel sanitary fittings advantages:
SS series stainless steel sanitary fitting has many advantages such as removable connection, simple structure, and easy maintenance;
SS series stainless steel sanitary fittings are high-quality pieces to ensure the use of performance and service life;
Adamant valves can provide fitting materials such as AISI 304 or AISI 316L, 304L and 316 materials, automated or manual operation valve according to your requests.

Showing 1–9 of 22 results

AV-13F Sanitary Fixed Spray Ball

Technical Parameters Technical Parameters Steel material Product wetted steel parts AISI 304 or 316L Provided with material inspection report (1.4306 / 1.4404) Other steel parts AISI 304 Pressure Working pressure ≤145psi (10bar) Supply pressure for air actuator 70 ~ 116psi (5 - 8bar) Surface treatment...

AV-13R Sanitary Rotating Spray Ball

Technical Specifications: Material:304/316L Stainless Steel Spray pattern: 360°

SS-ATWC Automatic Tube Weld Concentric Reducer

Specifications: Nom. Size A*T1 D*T2 L ATW-CR-020015 DN20*15 23.0*1.5 19.0*1.5 84.0 ATW-CR-025015 DN25*15 29.0*1.5 19.0*1.5 84.0 ATW-CR-025020 DN25*20 29.0*1.5 23.0*1.5 84.0 ATW-CR-032015 DN32*15 35.0*1.5 19.0*1.5 90.6 ATW-CR-032020 DN32*20 35.0*1.5 23.0*1.5 84.0

SS-ATWR Automatic Tube Weld Reducing Tee

Types Tee Reducing Weld x Weld x Short Outlet Clamp Automatic Tube Weld Reducing Tee Automatic Tube Weld 180° Reducing Tee

SS-CF Other Clamp Fittings

Sanitary clamp fittings are with sanitary clamp ends. They are widely used in pipeline systems for food, dairy, beverage, cosmetic, pharmaceutical, and fine chemical industries.

SS-EC Sanitary Solid End Cap

Tube OD × FNPT in A in B in Part Number 304 316L 0.50 0.98 0.18 SS14SEC-1/2-304 SS14SEC-1/2-316L 0.75 0.98 0.18 SS14SEC-3/4-304 SS14SEC-3/4-316L 1.00 1.98 0.25 SS14SEC-1-304 SS14SEC-1-316L 1.50 1.98 0.25 SS14SEC-1.5-304 SS14SEC-1.5-316L 2.00 2.51 0.25 SS14SEC-2-304 SS14SEC-2-316L 2.50 3.04 0.25 SS14SEC-2.5-304 SS14SEC-2.5-316L 3.00 3.57...

SS-HAC Hygienic Aseptic Connectors

Size:  DN10-DN100, 1/2"-4" Material:  1.4404/316L(welded flange and split ring) Surfaces: 20 Ra max (product contact surface) 47 Ra max (other surfaces) Operating pressure:  -15 - 100 psi Operating temperature: -110 - 390°F Connection styles:  Tri-Clamp DIN, ISO, and BS available upon request

SS-ILA I-line Adapters

Sanitary I-line fittings are with I-line ends. They are widely used in pipeline systems for food, dairy, beverage, cosmetic, pharmaceutical, and fine chemical industries.

SS-ILC I-line Clamps

Sanitary I-line fittings are with I-line ends. They are widely used in pipeline systems for food, dairy, beverage, cosmetic, pharmaceutical, and fine chemical industries.
