Sanitary Flange Description
Sanitary Fittings include sanitary elbows, sanitary tees, sanitary cross, sanitary clamps, sanitary ferrules, sanitary adapters, sanitary reducers, sanitary flanges, sanitary end caps and sanitary pipe holders.
Sanitary clamp fittings are with sanitary clamp ends. They are widely used in pipeline systems for food, dairy, beverage, cosmetic, pharmaceutical, and fine chemical industries.
Sanitary Flange Specification
Aseptic Flange Connections DIN 11864-2
| Size DN | Dimension (mm) | |||
| mm | OD/ID × t | A | B | F |
| 10 | 13/10 × 1.5 | 54.0 | 41.5 | 37.0 |
| 15 | 19/16 × 1.5 | 59.0 | 41.5 | 42.0 |
| 20 | 23/20 × 1.5 | 64.0 | 41.5 | 47.0 |
| 25 | 29/26 × 1.5 | 70.0 | 41.5 | 53.0 |
| 32 | 35/32 × 1.5 | 76.0 | 46.5 | 59.0 |
| 40 | 41/38 × 1.5 | 82.0 | 46.5 | 65.0 |
| 50 | 53/50 × 1.5 | 94.0 | 46.5 | 77.0 |
| 65 | 70/66 × 2.0 | 113.0 | 55.5 | 95.0 |
| 80 | 85/81 × 2.0 | 133.0 | 59.5 | 112.0 |
| 100 | 104/100 × 2.0 | 159.0 | 59.5 | 137.0 |
| Size | DN | D | D1 | H | |
| INCH | DIN | ||||
| 1″ | DN25 | 56 | 25.4 | 28.29 | 25 |
| 1 1/4″ | DN32 | 62 | 31.8 | 34.35 | 25 |
| 1 1/2″ | DN40 | 69 | 38.1 | 40.41 | 25 |
| 2″ | DN50 | 81 | 50.8 | 52.553 | 25 |
| 2 1/2″ | – | 91 | 63.5 | 52.53 | 25 |
| – | DN65 | 98 | – | 70 | 25 |
| 3″ | – | 104 | 76.2 | – | 25 |
| – | DN80 | 113 | – | 86 | 25 |
| 4″ | DN100 | 132 | 101.6 | 104 | 25 |
Sanitary Flange Materials:
SUS 304 AND SUS 316L
Standard:
ISO/DIN/GB/IDF
Sanitary Flange Application Scope:
Dairy,water,food,beer,beverage,pharmaceutical,cosmetic,chemical industry
Sanitary Flange Advantage:
Competitive price, punctual delivery, and guaranteed quality
