AV-1PL Sanitary Titanium Pneumatic Fluorine Lined Flange Butterfly Valve
Size 2” to 24” Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Weld, Clamp, Thread, Flange, etc Working Temp. -20 to 150℃ Working Pressure PN10, PN16
AV-1PMB Sanitary Powder Butterfly Valve with Tri-clamp Ends, SS Lever Handle
Specifications: Size 4”-10”, DN100-DN250 Body Material 316L, 304 Max working temperature 120°C, 180°C Surface Ra0.6μm; Ra0.4 μm Outside surface Matte, light, sand blast and electronic polishing Sealing material SILICON, FKM Connection Thread, clamp, flange, BSP, BSPT, NPT, DIN, or others upon request. Working atmosphere Vacuum,...
AV-1PPBH Sanitary Pneumatic Powder Butterfly Valve, Horizontal Aluminum Actuator
Specifications: 4''-10'', DN100-DN250 Connection method: clamp, welding, flange, bottom flange, DIN 3A INCH Material: 316L/1.4404/1.4435 Seal: White SILCON (recommended) Gray FKM (selection) Execution mode: manual, pneumatic, electric interchangeable
AV-1PPBV Sanitary Pneumatic Powder Butterfly Valve, SS Vertical Actuator
Specifications: Size 4”-10”/DN100-250 Working atmosphere vacuum, temperature up to 130°C, CIP cleaning and SIP sterilization Outside surface Matte, light, sandblast and electronic polishing Body Material 316L, 304 Sealing material SILICON, FKM Connection Tri-clamp, weld, flange, bottom flange Surface Ra0.6μm; Ra0.4 μm Standards 3A, DIN, SMS,...
AV-1PT Sanitary Butterfly Valves with Thread Ends, Pneumatic Operation
Specification: Reference No. : AV-1PT Sizes available: 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") DN15 - DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Material: Valve body and disc material can be AISI 304 or AISI 316L materials are available upon...
AV-1PV Sanitary Titanium Powder Butterfly Valve D08
Size DN65-DN300, 2.5''-12'' Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection clamp, weld, flange, bottom flange Max. Working Temp. 130℃ Working Pressure 10 bar
AV-1PW Sanitary Butterfly Valves with Butt-weld Ends, Pneumatic Operation
Specification Type Butterfly Valve Reference No. AV-1PW Sizes 1/2" to 12" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6", 8", 10", 12") Diameter Nominal DN15 - DN300 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300) Valve...
AV-1PWB Pneumatic 3-WAY Butterfly Valves
Size: 1”-4”, DN25-DN100 Material: 304/1.4301, 316L/1.4404, ASME BPE 316L 1.4435 NB2 Fe≤0.5% Pressure: Vacuum to 10 bar (1.0MPa) Temperature: EPDM -20℃ to +130℃, Depending on the seal material Seal: EPDM SILICON FKM FFKM HNBR FVMQ NBR Connection standard: DLN SMS ISO IDF RJT BS4825 ASME...
AV-1PWO Sanitary Wafer Butterfly Valve, Pneumatic Operation
Specifications: Size DN 50-300 Working temperature 0.6-1.6 Mpa Working pressure -20°C ~ +180°C Body material 304, 316L Sealing material EPDM, NBR, PTFE Finishing Ra <0.6 Standards ISO, DIN, IDF, SMS, 3A, etc.
