AV-21FB Flanged Brass Globe Valve
Materials: brass/bronze Size: DN15-DN150 Max Temp. : -20℃-120℃ Set Pressure: 1.6MPa Applicable Medium: water, non-corrosive medium
AV-21FG Flanged Globe Valve
Specifications: DN15-DN200, 1/2"-8" Nominal pressure: PN1.6-6.4, Class 150/300,10k/20k Strength test pressure: PT1.5PN High pressure seal pressure test: 1.1PN Applicable temperature: -40~180℃ Material: CF8, CF8M
AV-21MF Sanitary Manual Female Globe Valve
Material: CF8, CF8M Specifications: DN8-DN50, 1/2”-2” Nominal pressure: PN1 .6, 2.5, 4.0, 6.4 MPa Strength test pressure: 4, 3.8, 6.0, 9.6 MPa High pressure seal pressure test: 8, 2.8, 4.4, 7.1 MPa Applicable medium: J11W- (16-64) C water, oil, gas, J11W- (16-64) P nitric acid,...
AV-21MG Sanitary Manual 2-Way Globe Valve With Welded End, Manual Type
Specifications: Size 1/2”-3”, DN15 - DN80 Working temperature 130°C or 180°C Working pressure ≤8 bar or ≤10 bar Body material CF8/304, CF8M/316 Sealing material PTFE Connection Tri-Clamp, threaded, flange, welded Finishing Ra≤0.8 μm
AV-21MG1 Sanitary Manual 4-way 1-port Plug Valve with Tri-clamp
Specifications: Size 1/4”-1” Working temperature -10°C ~ 150°C Working pressure 0-10 bar Body material 316L Sealing material PTFE Connection Tri-Clamp Finishing Ra≤1.6 μm (outside surface) Ra≤0.8 μm (inside surface)
AV-21MG2 Sanitary Manual 4-way 2-port Plug Valve with Tri-clamp
Specifications: Size 1/4”-1” Working temperature -10°C ~ 150°C Working pressure 0-10 bar Body material 316L Sealing material PTFE Connection Tri-Clamp Finishing Ra≤1.6 μm (outside surface) Ra≤0.8 μm (inside surface)
AV-21PG Sanitary Pneumatic 2-way Globe Valve With Tri-clamp End
Specifications: Size 1/2”-3”, DN15 - DN80 Working temperature 130°C or 180°C Working pressure ≤8 bar or ≤10 bar Body material CF8/304, CF8M/316 Sealing material PTFE Connection Tri-Clamp, threaded, flange, welded Finishing Ra≤0.8 μm
AV-21TB Threaded Brass Globe Valve
Materials: brass/bronze Size: DN15-DN50 Max Temp. : -20℃-120℃ Set Pressure: 1.6MPa Applicable Medium: water, non-corrosive medium
AV-21TG Three-Way Globe Valve With Tri-clamp Ends, Pneumatic Type
Material of Sensor: Stainless steel Design Features: Specifications: 1/2"-4", DN10-DN80 Material: CF8/304, CF8M/316 Connection standard: thread, clamp, flange, BSP, BSP, NPT, DIN Working pressure: 8bar (standard) 10bar (optional) Working temperature: 120 ° C (standard) 180 ° C (optional)
