AV-10-S0424 Pneumatic Tank Bottom Valve
Specification DN25 / 1" to DN100 / 6" Material ASTM 304 / 1.4301, 316L / 1.4404 Gaskets EPDM, FPM, HNBR, FDA177.2600 Temperature -20°C to +150°C Certificate 3-A-53-06, PED/97/23/EC, FDA177.2600
AV-10-S0425 Tank Bottom Valve / Discharge Valve
Specification DN25 / 1" to DN100 / 4" Material ASTM 304 / 1.4301, 316L / 1.4404 Gaskets EPDM, FPM, HNBR, FDA177.2600 Temperature -20°C to +130°C Certificate 3-A-53-06, PED/97/23/EC, FDA177.2600
AV-10-S0436 Mixproof Tank Bottom Valve
Specification DN40-1.1/2" to DN100-4" Certificate 3-A-85-03, PED/97/23/EC, FDA 177.2600 Max. Operating Pressure 10 bar Temperature -10°C to +130°C Connection Welded connection (mm or inch)
AV-10BM Sanitary Tank Bottom Diaphragm Valve, Manual Type
Technical Specification: Size: 1”-4” DN25-DN100 Max. working pressure: 145psi (10bar) Working temperature range: -4° F to 302° F (-20°C to 150°C) Sterilization temperature: 302° F ( 150° C, MAX 20 min) Finish: <32Ra (<0.8 µm) Other finishes available upon request
AV-10BP Sanitary Tank Bottom Diaphragm Valve
Technical Specification: Size:1”-4” DN25-DN100 Max. pressure: 116psi (8bar) Control air pressure: 70-116 (5-8bar) Highest temperature range: Stainless steel actuator: -12° F to 302° F (-20°C to 150°C) Plastic actuator: -12° F to 266° F (-20°C to 130°C)...
AV-10MB Sanitary Tank Bottom Ball Valve With Tri-Clamp Ends, Manual Type
Specification: Size 1"-4"/DN25-DN100 Working pressure 0-10 bar (145psi) Outside surface Matte, light, sandblast and electronic polishing Body Material AISI 316L / AISI 304 Working temperature Stainless steel actuator: -12° F to 302° F (-20°C to 150°C) Plastic actuator: -12° F to 266° F (-20°C to...
AV-10MCB Multi-channel Bottom Diaphragm Valve
Multi-channel bottom diaphragm valve MG-32B Size: 1"-2", DN25-DN50 Material: 316L/1.4404, 1.4435 NB2 Fe＜5% Operations: Manual/Pneumatic Control: configurable, 1) Control Unit C-TOP, 2) positioner IL-TOP, 3) mechanical valve regulator, 4) Position Sensor
AV-10PB Sanitary Tank Bottom Ball Valve With Tri-Clamp Ends, Pneumatic Type
Specification: Size 1"-4"/DN25-DN100 Working pressure 0-10 bar (145psi) Outside surface Matte, light, sandblast and electronic polishing Body Material AISI 316L / AISI 304 Working temperature Stainless steel actuator: -12° F to 302° F (-20°C to 150°C) Plastic actuator: -12° F to 266° F (-20°C to...
AV-10PD Sanitary Pneumatic 2-way Double Seat Mix Proof Valve with Welded End
Specifications Size 1.5”-4”, DN40-DN100 Working temperature -10 °C ~130 °C Working pressure 0-10 bar Body material 304,316L Sealing material Viton, Silicone Connection Butt-welded, sanitary clamp, threaded, flange, DIN, SMS, RJT, IDF, or others upon request. Finishing <32Ra (<0.8µm); Other finishes available upon request.
