AV-5SS Sanitary Shutoff And Divert Valves
Materials Materials: AISI-316L Size available: DN25 - DN100/ 1"-4″ Seat materials: EPDM (Std), other seats available upon request. Elastomers: FPM (Std), EPDM (Opt) -- all seals complying with FDA21CFR177.2600 Technical Specification Size available: DN25-1" to DN100-4" Max. working pressure: 147psi (10bar) Control air pressure: 70...
AV-6 Sanitary Divert Seat Valves with Butt-weld Ends, Manual Type
Materials Materials: AISI-316L/ AISI 304 Size: 1''-2'' Plug and seal: EPDM, or others upon request. Standard Design Valve body and valve stem with stopper are made of stainless steel AISI 304 or acid-resistant stainless steel AISI 316L. Valve body OD sand polished, valve stem is strengthened...
AV-7A Aseptic Sampling Valves
Materials: AISI-316L Size: DN8 Diaphragm: Silicone (for standard valve), EPDM (for valve with micro type connector) Technical Specification Nominal Pressure: Max. product pressure: 87psi (6bar) Temperature: Max. sterilization temperature: 130°C, dry steam: 121°C (2bar). Steam must be dry, because condensed water will damage the diaphragm....
AV-7G Sanitary Gauges
Materials: AISI-316L Size: 1/4''-3/4'' Seals: PTFE Technical Specification End connection: threaded, clamp, welded as customers require. Size available: 1/4", 3/8", 1/2", 3/4" Max. working pressure: 147psi (10bar) Min. working pressure: Applicable under vacuum Working temperature: 14 ~ 248°F (-10 ~ 120°C)
AV-7N Sanitary No Retention Sampling Valve
Specifications: Size 1/4”, 3/8”, 1/2”, 3/4”, 1”, 2” Working temperature -10 ° C to 130 ° C Body material AISI 304 AISI 316L Sealing material PTFE Connection clamp, thread, welding, nut type Standards ISO, DIN, SMS, RJT
AV-7P Sanitary Piston Valve
Materials: Stainless Steel 304/316L, Seat Material: Viton, silicon, PTFE Max Working Pressure: 12 bar (174 psi) Special characteristics: Side pipe sanitary sampling valves are designed for sampling of liquids on pharmaceutical, chemical, F&B and cosmetics products. O-Ring closing system.
AV-7PA Pneumatic Type Aseptic Sampling Valves
Materials: AISI-316L Size: DN8 Diaphragm: Silicone (for standard valve), EPDM (for valve with micro type connector) Technical Specification Nominal Pressure: Max. product pressure: 87psi (6bar) Temperature: Max. sterilization temperature: 130°C, dry steam: 121°C (2bar). Steam must be dry, because condensed water will damage the diaphragm....
AV-7S Sanitary Sampling Valves
Materials Materials: AISI-316L Size: 1/4''-3/4'' Seals: PTFE Gasket: EPDM or NBR Standard Design End connection: threaded, clamp, welded as customers require. Sampling port size available: 1/4", 3/8", 1/2",3/4" Max. working pressure: 10bar Max. working temperature: 248°
AV-7SV Straight Sampling Valves
Working Temperature: -10℃ to -130℃ Body material: AISI 304 AISI 316L Seal material: PTFE Connection: clamp, threaded, welded
