AV-3F Sanitary Flange Connected Check Valves with Welded Ends
Specifications Size 1”, 1.5”, 2”, 2.5”, 3”, 4” Max. working temperature 140°C Max. working pressure 10 Bar Body material 316L/304 Sealing material VITON, SILICON, EPDM Connection Welded, thread, clamp Finishing Ra<0.8μm Standards ISO/DIN/ASME BPE/3A/BS/GB
AV-3N Sanitary Nut Check Valve
Specifications: Size DN25-DN100, 1”-4” Working temperature -10 °C to 130 °C Working pressure 10bar Body material AISI 316L/304 Sealing material EPDM Connection Weld, thread, tri-clamp Finishing Ra<0.8 μm Standards DIN, SMS,RJT, IDF, ISO, 3A
AV-3P Three Piece Check Valve
Casing/Shaft: AISI 316L/AlSI 304 Spring: AISI 301 Surface Finishing: Ra≤0.8μm Max. Pressure: 0.3bar (DN25) 0.2bar (DN32/40) 0.1bar (DN20/100) Operating Temp. : -10℃ to +120℃ (EPDM)
AV-3S High Performance Swing Check Valve
Specifications: Size DN 2-12 Working temperature -10 ~ 110°C Working pressure 16 Bar Max. Body material 316 L/ aluminum bronze Sealing material NBR
AV-3T Sanitary Check Valve with Thread Ends
Specification: Sizes are available from 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") DN15 to DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve body can be AISI 304 or AISI 316L. Valve seat: EPDM, VMQ (silicone), Viton (FPM)...
AV-3TC Sanitary Spring Check Valves with Tri-Clamp
Specifications Size 1”, 1.5”, 2”, 2.5”, 3”, 4” Max. working temperature 140°C Max. working pressure 10 Bar Body material 316L/304 Sealing material VITON, SILICON,EPDM Connection Welded, thread, clamp Finishing Ra<0.8μm Standards ISO/DIN/ASME BPE/3A/BS/GB
AV-3W Sanitary Check Valve with Butt-weld Ends
Specification: Sizes are available from 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") DN15 to DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve body can be AISI 304 or AISI 316L. Valve seat: EPDM, VMQ (silicone), Viton (FPM)...
AV-4-S0392 Manual Diaphragm Valve With Lock
Specification 1 in-4 in/DN20-DN100 Working Pressure Full Vacuum ~ 10 bar Working Temperature -10℃ to 120℃ Applicable Media Water, oil, gas, and other media Connection Clamp, Weld, Thread, Flange
AV-4-S0393 Manual Diaphragm Tank Bottom Valve
Specification 1"–4", DN25–DN100 Working Pressure Full Vacuum ~ 10 bar Working Temperature -20℃ to +150℃ Diaphragm Materials EPDM+PTFE (dual layer) / EPDM / Silicone / FKM (Viton) Connection Types Clamp, weld, thread; 3A, BPE, DIN, SMS, IDF, ISO
