AV-4US U Shape Three-way Diaphragm Valve
Materials: 316L/1.4404 Size: 1"-4", DN25-DN100 Working Temp. : -20 to 150℃ Set Pressure: 10 bar Connection clamp: clamp, welding, and other special connection
AV-4UT U Type Reducing Diaphragm Valve G08.2
Size DN15-273MM Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, thread, flange, etc. Working Temp. -20 to 150℃ Set pressure 1.6Mpa
AV-4UV U Type Diaphragm Valve G03.3
Size DN8-DN100 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, flange Working Temp. -20 to 150℃ Working pressure ≤16Mpa
AV-4VG 4-position 4-way Titanium Diaphragm Valve G0944.1
Size 3/4"-2.5", DN20-DN65 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Outlet Connection Clamp, weld, Special interface Working Temp. -20 to 120℃ Max. pressure 10 bar
AV-4WD 2-position 3-way Titanium Diaphragm Valve G0923.3
Size 1/4”-3/4”, DN6-DN15 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, thread, flange, etc. Working Temp. -20 to 150℃ Set pressure 10 bar
AV-4WG 4-position 5-way Titanium Diaphragm Valve G0945.2
Size 3/4"-2.5", DN20-DN65 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Outlet Connection Clamp, weld, Special interface Working Temp. -20 to 120℃ Max. pressure 10 bar
AV-4WV 4-position 4-way Titanium Diaphragm Valve G0944.4
Size 1/4”-3/4”, DN6-DN15 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, thread, flange, etc. Working Temp. -20 to 150℃ Set pressure 10 bar
