Showing 46–54 of 160 results

AV-1MF Sanitary Flange Butterfly Valves with Pull Handle

Specification Size 1/2”-10”(DN10-DN200) Working temperature 14 ~ 248°F (-10 ~ 120°C) with EPDM seat, -58 ~ 356°F (-50 ~ +180°C) with VMQ (Silicone) seat. Working pressure Up to 145psi (10bar) for DN15/0.5″-DN100/4″, 116psi (8bar) for DN125/5″-DN150/6″, 73psi (5bar) for DN200/8″ Material Valve body and disc...

AV-1MI Sanitary I-line Butterfly Valves with Pull Handle

Specification: Reference No. : AV-1MI-P Sizes available: 1'' to 6'' (1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6") DN25 - DN150 (DN25, DN40, DN50, DN65, DN80, DN100, DN125, DN150) Material: Valve body and disc material can be AISI 304 or AISI 316L, 304L and 316 materials...

AV-1MT Sanitary Thread Butterfly Valves with Pull Handle

Specification Type Butterfly Valve Reference No. AV-1MT-P Sizes 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") Diameter Nominal DN15 - DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve body material AISI 304 or AISI 316L, 304L and 316 materials...

AV-1MTE Sanitary 3-Way Manual Butterfly Valve With Threaded Ends

Specifications Size 1”-4”, DN25-DN100 Working temperature 130 °C Max. Working pressure 10 bar Max. Body material 304, 316L Sealing material EPDM, VMQ, FPM Connection Welded, threaded, flange, and tri-clamp Standards DIN SMS RJT Inch

AV-1MW Sanitary Butt-weld Butterfly Valve with Pull Handle

Specification  Type Butterfly Valve Reference No. AV-1MW-P Sizes 1/2" to 12" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6", 8", 10", 12") Diameter Nominal DN15 - DN300 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300) Valve...

AV-1PC Sanitary Pneumatic Butterfly Valve Actuator with Tri-clamp Ends

Specification Type Butterfly Valve Reference No. AV-1PC Sizes 1/2" to 12" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6", 8", 10", 12")1" to  4" (1”, 1 1/2", 2", 2 1/2", 3", 4") Diameter Nominal DN15 - DN300 (DN15, DN20, DN25, DN40, DN50,...

AV-1PF Sanitary Butterfly Valves with Flange Ends, Pneumatic Operation

Specification: Reference No. : AV-1PF Sizes available: 1" - 10" (1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6", 8", 10") DN25 – DN250 (DN25, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250) Material: Valve body and disc material can be AISI 304 or AISI 316L,...

AV-1PI Sanitary Butterfly Valves with I-line Ends, Pneumatic Operation

Specification: Reference No. : AV-1PI Sizes available: 1" to 6" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6") DN25 - DN300 (DN25, DN40, DN50, DN65, DN80, DN100, DN125, DN150) Material: Valve body and disc material can be AISI 304 or AISI 316L, 304L and...

AV-1PMB Sanitary Powder Butterfly Valve with Tri-clamp Ends, SS Lever Handle

Specifications: Size 4”-10”, DN100-DN250 Body Material 316L, 316 Max working temperature  120°C, 180°C Surface Ra0.6μm; Ra0.4 μm Outside surface  Matte, light, sand blast and electronic polishing Sealing material SILICON, FKM Connection Thread, clamp, flange, BSP, BSPT, NPT, DIN, or others upon request. Working atmosphere Vacuum,...
