Showing 55–63 of 178 results

AV-1PPB Sanitary Pneumatic Powder Butterfly Valve with Tri-clamp Ends

Specifications: Size 4”-10”/DN100-250 Working atmosphere  vacuum, temperature up to 130°C, CIP cleaning and SIP sterilization Outside surface Matte, light, sandblast and electronic polishing Body Material 316L, 304 Sealing material SILICON, FKM Connection Tri-clamp, weld, flange, bottom flange Surface  Ra0.6μm; Ra0.4 μm Standards 3A, DIN, SMS,...

AV-1PT Sanitary Butterfly Valves with Thread Ends, Pneumatic Operation

Specification: Reference No. : AV-1PT Sizes available: 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") DN15 - DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Material: Valve body and disc material can be AISI 304 or AISI 316L materials are available upon...

AV-1PW Sanitary Butterfly Valves with Butt-weld Ends, Pneumatic Operation

Specification  Type Butterfly Valve Reference No. AV-1PW Sizes 1/2" to 12" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4", 5", 6", 8", 10", 12") Diameter Nominal DN15 - DN300 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300) Valve...

AV-1PWO Sanitary Wafer Butterfly Valve, Pneumatic Operation

Specifications: Size DN 50-300 Working temperature 0.6-1.6 Mpa Working pressure -20°C ~ +180°C Body material 304, 316L Sealing material EPDM, NBR, PTFE Finishing Ra <0.6 Standards ISO, DIN, IDF, SMS, 3A, etc.

AV-1RTPC Regulation Type Pneumatic Butterfly Valve

Specifications: Size 1”-4”; DN25-DN100 Material 304/316L Connection Clamp, weld, thread, flange and other standards Working Temperature 130 Degree Centigrade Work Pressure 10bar Support DEVICE NET BUS Acting Singe-acting(standard), double- acting(option Power Suppliy DC 24V ±10% Analog Signals 0/4-20Ma,0-5/10V

AV-1UE Sanitary Manual Butterfly Valves with Union End

Specifications: Size 1" ~ 4", DN 25 ~ DN 150 Working temperature -10°C to 135°C with EPDM seal -10°C to 170°C with Silicone seal -10°C to 200°C with FKM seal Working pressure Maximum 10 bar Body material Stainless Steel 304 & 316L Sealing material EPDM,...

AV-1WHO Sanitary Wafer Butterfly Valve, Handle Operator

Specifications: Size DN 50-300 Working temperature 0.6-1.6 Mpa Working pressure -20°C ~ +180°C Body material 304, 316L Sealing material EPDM, NBR, PTFE Finishing Ra <0.6 Standards ISO, DIN, IDF, SMS, 3A, etc.

AV-20 Sanitary Filling Valve With Internal Sealing

Specifications: Size ΦD=12-20 mm Working temperature -10°C - +80°C Medium temperature -10°C - 120°C Controlling pressure 3-3.5 bar(44-51psi) Working pressure 0-7 bar(0-102psi) Body material 316 Sealing material PTFE

AV-21MG Sanitary Manual 2-Way Globe Valve With Welded End, Manual Type

Specifications: Size 1/2”-3”, DN15 - DN80 Working temperature 130°C or 180°C Working pressure ≤8 bar or ≤10 bar Body material CF8/304, CF8M/316 Sealing material PTFE Connection Tri-Clamp, threaded, flange, welded Finishing Ra≤0.8 μm
