AV-4MG Mini Titanium Diaphragm Valve G01

Availability : In stock

Mini type sizes available: 1/4″, 3/8″, 1/2″, 3/4″

Valve body: Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2

Valve seat: EPDM+PTFE

Max. working pressure: 145psi (10bar)

Working temperature range: -22 ~ 266℉(-30 ~ 130℃) or higher upon request

Inside treatment: Ra 16-32μin (0.4-0.8μm), Ra 25 (0.5μm) is the default.

Mini Titanium Diaphragm Valve G01 Description

Mini Titanium Diaphragm Valve G01 is a manual type sanitary mini diaphragm valve made of Titanium TA1/TA2. The valve is excellent for flow control as well as for open/close duties. It is mainly used for sampling, biological systems, laboratory engineering, etc. This field-proven and industry preferred valve is better than the Stainless Steel Valve in preventing the corrosion of fasteners.

Mini Titanium Diaphragm Valve G01 Specifications

Size	1/4″, 3/8″, 1/2″, 3/4″
Body material	Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2
Valve seat	EPDM+PTFE
Max. working pressure	145psi (10bar)
Working temperature range	-22 ~ 266℉(-30 ~ 130℃) or higher upon request
Inside treatment	Ra 16-32μin (0.4-0.8μm), Ra 25 (0.5μm) is the default.

Mini Titanium Diaphragm Valve G01 Applications

Mini Titanium Diaphragm Valve G01 is widely used in food, beverage, dairy, brewing, pharmaceutical industries, etc. It is excellent for flow control as well as for open/close duties.
