AV-2CQ Sanitary Titanium Clamp Ball Valve Q8.1
Availability :
In stock
| Sizes | 1/2″ to 4″ |
| Diameter Nominal | DN15 to DN100 |
| Valve body material | Hastelloy C276/C22 Monel 400,
254SMO N08904 Titanium TA1/TA2 |
| Max. working pressure | 10 bar |
| Temperature range | -10 ~150℃ |
Sanitary Titanium Clamp Ball Valve Q8.1 Description
Sanitary Titanium Clamp Ball Valve Q8.1 is an all-inclusive ball seat design, which solves the problem of liquid retention in the valve cavity of the ball valve. The ball valve is suitable for biopharmaceutical engineering. It withstands high temperature of 150 ℃ for long-term use.
Sanitary Titanium Clamp Ball Valve Q8.1 Specifications
| Sizes | 1/2″ to 4″ |
| Diameter Nominal | DN15 to DN100 |
| Valve body material | Hastelloy C276/C22 Monel 400,
254SMO N08904 Titanium TA1/TA2 |
| Max. working pressure | 10 bar |
| Temperature range | -10 ~150℃ |
| Surface Finish | Ra 32μin (0.8μm) as default, Ra 16μin (0.4μm) as best. |
| End connection | Tri-clamp |
Sanitary Titanium Clamp Ball Valve Q8.1 Applications
Sanitary Titanium Clamp Ball Valve Q8.1 is suitable for biopharmaceutical engineering.
